Designed to work with the following winches:
- KFI on VIKING: ST17 / A2000 / A2500-R2 / A3000 / U45-R2 / SE25 / SE35 / SE45-R2 / AS-50 / AS-50w (Will NOT work with U45w-R2 or SE45w-R2 WIDE winches)
- KFI on WOLVERINE: ST17 / A2000 / A2500-R2 / A3000 / SE25 / SE35 / AS-50 / AS-50w (Will NOT work with U45-R2, U45w-R2, SE45-R2 or SE45w-R2 winches)
- WARN: A2000 / A2500 / U2500 / 1.5ci / 2.5ci / 2.5ce / 3.0ci / 3.0ce / 3.0s
- WARN: RT15 / RT25 / RT30 / XT15 / XT25 / XT30
- WARN: RT40 / XT40 (Requires the drilling of two holes)
- WARN: Vantage 2000-3000lb
- WARN: Vantage 4000lb (Requires the drilling of two holes)
- WARN: ProVantage 2500-3500lbs
- WARN: ProVantage 4500lbs (Requires the drilling of two holes)
- RAMSEY : ATV2500 / ATV3000
- SUPERWINCH : Terra25 / Terra35 / LT2000 / LT2500 / LT3000 / LT4000ATV / LT4000UTV
- SUPERWINCH : Terra 45 (Requires drilling of two holes)
- MILE MARKER : PE2.5 / PE 3.5 / VMX2.5 / PE2000 / PE3000 / PE2500 / PE3500 (2-hole mounted winches will require the drilling of one hole)
- CYCLE COUNTRY : Work Power 1500 and 2500 / Powermax 2500 and 3500
- BADLAND: 2-Hole Winches
- (Requires drilling of hole(s))
- BADLAND: Standard Winches
- BADLAND: WIDE Winches
- (Requires drilling of two holes)
- CHAMPION : 2-Hole Winches
- CHAMPION : Standard Winches
- CHAMPION : WIDE Winches
- (Requires drilling of two holes)
- Possibly many others with the below standard mounting patterns, call to confirm.
- 4-Hole (3.00" x 4.875" bolt pattern with rollers that are 4.875" bolt pattern)
- 4-Hole WIDE that will require the drilling of two holes (3.00" x 6.60" bolt pattern with rollers that are 6.600" or 6.000" bolt pattern)
- 2-Hole that will require the drilling of one hole (3.10" with rollers that are 4.875" bolt pattern)
No Reviews Available
Installation
Most of our products come shipped with installation instructions. But we know sometimes things can be a little trickier than they seem. If you need some assistance installing this prouct, drop us a line and one of our friendly staff can give you some advice.
