Designed to work with the following winches:

  • OZ ARMOUR: EWX2000A / EWP2500A / EWP2500ASR / EWP3500ASR
  • MILLER UTILITY: EWP3500A
  • KFI on VIKING / Viking VI: ST17 / A2000 / A2500-R2 / A3000 / U45-R2 / SE25 / SE35 / SE45-R2 /AM-25 / AM-35 / AS-25 / AS-35 / AS-50 / AS-50w (Will NOT work with U45w-R2 or SE45w-R2 WIDE winches)
  • KFI on WOLVERINE: ST17 / A2000 / A2500-R2 / A3000 / SE25 / SE35 / AM-25 / AM-35 / AS-25 / AS-35 / AS-50 / AS-50w (Will NOT work with U45-R2, U45w-R2, SE45-R2 or SE45w-R2 winches)
  • KFI on WOLVERINE X2 and X4: ST17 / A2000 / A2500-R2 / A3000 / U45-R2 / U45w-R2 / SE25 / SE35 / SE45-R2 / SE45w-R2 / AM-25 / AM-35 / AS-25 / AS-35 / AS-50 / AS-50w
  • WARN: VRX 25 / VRX 25-S / VRX 35 / VRX 35-S
  • WARN on WOLVERINE X2 and X4: AXON 35 / AXON 35-S / AXON 45RC
  • WARN: A2000 / A2500 / U2500 / 1.5ci / 2.5ci / 2.5ce / 3.0ci / 3.0ce / 3.0s
  • WARN: RT15 / RT25 / RT30 / XT15 / XT25 / XT30
  • WARN: RT40 / XT40 (Requires the drilling of two holes)
  • WARN: Vantage 2000-3000 lb
  • WARN: Vantage 4000 lb (Requires the drilling of two holes)
  • WARN: ProVantage 2500-3500 lb
  • WARN: ProVantage 4500 lb (Requires the drilling of two holes)
  • RAMSEY: ATV2500 / ATV3000
  • SUPERWINCH: Terra25 / Terra35 / A3500 / LT2000 / LT2500 / LT3000 / LT4000ATV / LT4000UTV
  • SUPERWINCH: Terra 45 (Requires drilling of two holes)
  • MILE MARKER: PE2.5 / PE 3.5 / VMX2.5 / PE2000 / PE3000 / PE2500 / PE3500 (2-hole mounted winches will require the drilling of one hole)
  • CYCLE COUNTRY: Work Power 1500 and 2500 / Powermax 2500 and 3500
  • BADLAND: 2-Hole Winches
    • (Requires drilling of hole(s))
  • BADLAND: Standard Winches
  • BADLAND: WIDE Winches
    • (Requires drilling of two holes)
  • CHAMPION: 2-Hole Winches
  • CHAMPION: Standard Winches
  • CHAMPION: WIDE Winches
    • (Requires drilling of two holes)
  • KEEPER CORP. TRAKKER: KT2500 / KT3000 / KT2500C / KT3000C
  • KEEPER CORP. TRAKKER: KT4000 / KT4000C (Requires the drilling of two holes)
  • KEEPER CORP. TRAKKER: KT2000 (Requires the drilling of one holes)
    • Requires roller fairlead with a 124 mm (4.875") bolt pattern.
  • SMITTYBILT: XRC 2.0 (Requires drilling of one holes)
    • Requires roller fairlead with a 124 mm (4.875") bolt pattern.
    • Listed models come with incorrect ATV roller fairleads.
  • SMITTYBILT: XRC 3.0 / XRC 4.0
  • XGEAR: X3000 / X4000
    • 4-Hole Standard (76 mm [3.00"] x 124 mm [4.875"] bolt pattern)
  • VENOM: 2000 / 2500 / 3000 / 3500 / 4000 / 4500 / 5000 (Hardcore Series)
    • All with 76 mm (3.00") x 124 mm (4.875") bolt pattern mount-up.
    • All with 76 mm (3.00") x 168 mm (6.600") bolt pattern mount-up will require the drilling of two holes.
  • TRAVELLER:1078088/ 1078302
    • Requires roller fairlead with a 124 mm (4.875") bolt pattern.
  • Possibly many others with the below standard mounting patterns:
    • 4-Hole (76 mm [3.00"] x 124 mm [4.875"] bolt pattern with rollers that are 124 mm [4.875"] bolt pattern)
    • 4-Hole WIDE that will require the drilling of two holes (76 mm [3.00"] x 168 mm [6.600"] bolt pattern with rollers that are 168 mm [6.600"] or 152 mm [6.000"] bolt pattern)
    • 2-Hole that will require the drilling of one hole (79 mm [3.10"] with rollers that are 124 mm [4.875"] bolt pattern)
  • 100% made in USA
  • Constructed of 3⁄16" steel
  • Unlike all other mount competitors, our mounts are metal blasted before they are powder coated for the best possible finish
  • Powder coated black for supreme durability
  • Very easy to install
  • Complete installation instructions included
  • All mounting hardware included
  • Satisfaction guaranteed
  • Roller fairlead and winch not included
FITTING NOTES
  • This mount can not fit a 4500 lb Winch

Download Yamaha Viking/ Wolverine & X4/ X2 Winch Mount Instructions

This product fits the following vehicle models:

  • Yamaha Viking 700 - 2014^
  • Yamaha Viking 700 EPS - 2015-2024^
  • Yamaha Viking 700 EPS Camo - 2015-2018^
  • Yamaha Viking 700 EPS SE - 2014-2024^
  • Yamaha Viking FI 4x4 EPS - 2014^
  • Yamaha Viking VI - 2014-2022^
  • Yamaha Wolverine 700 EPS - 2015-2018
  • Yamaha Wolverine 700 EPS Camo - 2015-2016
  • Yamaha Wolverine 700 R-Spec - 2015-2016
  • Yamaha Wolverine X2 - 2019
  • Yamaha Wolverine X2 R-Spec - 2018-2019
  • Yamaha Wolverine X4 - 2018-2019

^ Fitting requires two holes to be drilled in mount

Warranty Period: 12 Months

This product is covered by the warranty period listed above.

Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure.

Refer to the following links for access to Aussie Powersports detailed Warranty Policy and Terms & Conditions of Purchase:

Click here to read Aussie Powersport's Warranty Policy

Click here to read Aussie Powersport's Term & Conditions of Purchase

SKU 101515
Brand KFI PRODUCTS
Shipping Weight 3.7000kg
Shipping Width 0.270m
Shipping Height 0.130m
Shipping Length 0.300m
Shipping Cubic 0.010530000m3
